PFA Films

PFA Films by Techbelt

Our PFA (Perfluoroalkoxy) Films at Techbelt boast an exceptionally high continuous service temperature of 500°F (260°C). PFA is a fluoropolymer resin known for its outstanding heat resistance and versatile applications.

Key Features of PFA Resin

• Heat Sealing and Thermoforming: PFA resin can be easily heat sealed and thermoformed.
• Metalization: It can be metalized for enhanced performance.
• Lamination: Ideal for lamination to various materials, making it suitable for diverse end-user applications.
• Hot Melt Adhesive: Serves as an effective hot melt adhesive.
• Appearance: PFA generally appears clear or translucent, with performance characteristics similar to PTFE (Polytetrafluoroethylene).
• Temperature Range: PFA operates impressively from -100°F (-73°C) to 500°F (260°C).
• Clarity and Durability: Offers excellent clarity, durability, and dielectric properties.

Applications of PFA Films

PFA is virtually chemically inert, making it ideal for high-temperature and chemically resistant applications. Common uses include:

• Rupture Disks
• Chemical Pumps
• Tank Linings
• Shrink Roll Covers
• Gaskets

Its durability and resistance to flexing and cracking make it suitable for:

• Flat Cables
• Circuit Board Manufacturing
• Diaphragms

Grades of PFA Films

We offer two grades of PFA films:

1. Welding Grade (PFA WG): Cost-effective, providing all essential mechanical, physical, and thermal properties. Typically, it offers about a 15% savings over premium grade.
2. Premium Grade (PFA PG): Known as virgin PFA, made with 100% PFA resin, and has a melt flow index (MFI) range of 1.5 – 2.5.

Specifications and Availability

• Rolls: Available at 12kg rolls with short lead times.
• Thicknesses: Standard thicknesses are 0.002 inches (0.05mm) and 0.005 inches (0.125mm).
• Widths: Standard widths are 48 inches (1220mm) and 60 inches (1524mm).
