PTFE coated material fabrics

Below is a Technical overview of some standard products within our range of PTFE coated material fabrics

Non Adhesive Closed Weave Products

Tefsil 3

  • Coated Weight 150g/m2 – 0.08mm nominal thickness
  • Max Temperature 260°C
  • Max Width 1500mm

Tefsil 3 is a thin PTFE coated glass cloth. This material is ideally suited as a release cloth for films on packaging machines. They are supplied in slit roll form ranging from 10mm to 1000mm wide and on 30mtr coils. We also sell these products by the square meter.

Tefsil 5

  • Coated Weight 250g/m2 – 0.125mm nominal thickness
  • Max Temperature 260°C
  • Max Width 200mm

Tefsil 5 is a thinner PTFE coated glass cloth. This material is ideally suited as a release cloth for films on packaging machines as well as release sheets. They are supplied in slit roll form ranging from 10mm to 1000mm wide and on 30mtr coils. We also sell these products by the square meter.

Tefsil 6

  • Coated Weight 300g/m2 – 0.15mm nominal thickness
  • Max Temperature 260°C
  • Max Width 2000mm

Tefsil 6 is a premium coated PTFE coated glass cloth. This material is ideally suited as a release cloth for films on packaging machines as well as UPVC window frame welders. They are supplied in slit roll form ranging from 10mm to 1000mm wide and on 30mtr coils. We also sell these products by the square meter.

Tefsil 10

  • Coated Weight 485g/m2 – 0.25mm nominal thickness
  • Max Temperature 260°C
  • Max Width 2600mm

Tefsil 10 is a thicker PTFE coated glass cloth. This material is ideally suited as release sheets as well as being made in to conveyor belt for packaging machines. They are supplied in slit roll form ranging from 10mm to 1000mm wide and on 30mtr coils. We also sell these products by the square meter.

Tefsil 14

  • Coated Weight 560g/m2 – 0.34mm nominal thickness
  • Max Temperature 260°C
  • Max Width 2600mm

Tefsil 14 is a thicker PTFE coated glass cloth. This material is ideally suited to be made in to conveyor belts. They are supplied in slit roll form ranging from 10mm to 1000mm wide and on 30mtr coils. We also sell these products by the square meter. The fiberglass used in thicker than all other grades.

PS-26-NA (blue)

  • Coated Weight 530g/m2 – 0.25mm nominal thickness
  • Max Temperature 260°C
  • Max Width 1100mm

PS-26-NA (blue) is a premium grade ptfe coated glass cloth. It has a blue pigment and is especially designed for use in the food processing industry, in particular flat breads. This material is generally supplied as finished belts.

AS-25-NA

  • Coated Weight 500g/m2 – 0.25mm nominal thickness
  • Max Temperature 260°C
  • Max Width 2600mm

AS-25-NA is a black carbon loaded PTFE coated glass cloth. It is designed to be anti-static. This material is ideally suited as a conveyor belt for packaging machines as well as garment fusing belts. We also supply this as roll goods of PTFE coated material fabrics for companies who manufacture their own belts.

AS-37-NA

  • Coated Weight 700g/m2 – 0.40mm nominal thickness
  • Max Temperature 260°C
  • Max Width 2600mm

AS-37-NA is a thicker PTFE coated glass cloth. This material is ideally suited as to being made into conveyor belts for fabric and composite laminating. It is also extensively used as finished sheets for solar panel production / laminating. We can supply this material in roll form depending on requirement.

PS-68-NA

  • Coated Weight 1150g/m2 – 0.68mm nominal thickness
  • Max Temperature 260°C
  • Max Width 2600mm

PS-68-NA are heavy grade PTFE coated material fabrics. This material is ideally suited as to being made into conveyor belts carpet back curing. Our PTFE coated material fabrics are generally textured which provides an impression when used to manufacture walk off mats.

Open Mesh Products

GM-72-NA

  • Coated Weight 530g/m2 – 0.645mm nominal thickness
  • Max Temperature 260°C
  • Max Width 3200mm

GM-72-NA is a 1mm square aperture ptfe coated mesh. This suited for use as a finished conveyor belt when used for drying and conveying smaller products such as cereal products. We can manufacture any belt size up to 3200mm wide and your required length.

GM-82-NA

  • Coated Weight 455g/m2 – 0.82mm nominal thickness
  • Max Temperature 260°C
  • Max Width 3600mm

GM-22-NA is a 2mm square aperture ptfe coated mesh. This suited for use as a finished conveyor belt when used for drying and conveying smaller products such as cereal products where more airflow is required. We can manufacture any belt size up to 3200mm wide and your required length.

GM-95-NA

  • Coated Weight 470g/m2 – 0.95mm nominal thickness
  • Max Temperature 260°C
  • Max Width 5000mm

GM-95-NA is a 4mm square aperture ptfe coated mesh. This suited for use as a finished conveyor belt when used for drying and curing inks on screen printed products such as point of displays and t shirts. We can manufacture any belt size up to 5200mm wide and your required length. 4000mm wide is our general stock width.

GM-95-AS

  • Coated Weight 470g/m2 – 0.95mm nominal thickness
  • Max Temperature 260°C
  • Max Width 4000mm

GM-95-NA is a 4mm square aperture PTFE coated material fabrics mesh. This black product has a carbon loading in the ptfe giving it anti-static properties. This is suited for use as a finished conveyor belt when used for drying and curing inks on screen printed products such as point of displays and t shirts.

GM2-95-NA

  • Coated Weight 546g/m2 – 1.128mm nominal thickness
  • Max Temperature 260°C
  • Max Width 5000mm

GM2-95-NA is a 4mm square aperture ptfe coated mesh. Is benefits from a double weft yarn which gives is much more stability. This suited for use as a finished conveyor belt when used for drying textiles or curing beverage cans. This is our most popular mesh product.

GM-155-NA is a 5mm square aperture ptfe coated mesh. This suited for use as a finished conveyor belt when used for drying and curing inks on screen printed products such as point of displays and t shirts. This material is suited to applications where slightly more air flow is required.

KM-90-NA

  • Coated Weight 285g/m2 – 0.90mm nominal thickness
  • Max Temperature 220°C
  • Max Width 5000mm

KM-90-NA is a 4mm square aperture ptfe coated aramid mesh. This suited for use as a finished conveyor belt when used for drying products that may require a stronger belt due to the nature of the process. Also food products that are steamed benefit from this grade as it doesn’t suffer from the effects of steam like glass fabric belts.

KG-155-NA

  • Coated Weight 575g/m2 – 1.252mm nominal thickness
  • Max Temperature 260°C
  • Max Width 3700mm

KG-155-NA is a 4mm square aperture ptfe coated mesh. Is has an aramid yarn in its waft and a fiberglass yarn in its weft. This suited for use as a finished conveyor belt when used for drying fabrics in a relax dryer where light moisture is present. It is a heavier duty mesh so is also suited to applications where a strong belt is needed.

Please contact Techbelt today on 0044 (0)1422 366386 to discuss your PTFE coated material fabrics.
